Каталог запчастей для Lexmark X925 - Covers

№	Номер партии	Описание

1	40X6126	Complete Duplex
10	40X6289	Upper front logo cover
11	40X6282	Right hinge
12	40X6280	Front cover
13	40X6283	Left hinge
14	40X6122	Left cover
15	40X6124	Access cover
16	40X6369	Option cable
17	40X6125	Option cover
18	40X6298	Back cover
19	40X6297	Cable cover
2	40X6272	A/S link arm spring
20	40X6296	Printer top cover
21	40X6743	Op panel paper exit guide
22	40X6417	Output bin full lever
23	40X6273	B/S link arm spring
24	40X6269	B/S link arm
25	40X6270	Safety switch spring
26	40X6267	Release link
27	40X6271	Release spring
28	40X6294	Back cave cover
29	40X6301	Inner right cover
3	40X6268	A/S link arm
30	40X6295	Upper right cover
4	40X6302	Op panel front cover w/card reader
4	40X6303	Op panel front cover
5	40X6120	Paper size sensor cable
6	40X6114	Paper size sensor
7	40X6354	Sensor frame
8	40X6121	Tray stop
9	40X6169	Transfer belt door (DS Lock)
NS	40X6292	RIP cover
NS	40X6314	Cave light cable
NS	40X6499	Cover 1 screw parts pack
NS	40X6304	Cave LED cover
NS	40X6744	Op panel under cover. (used on 40X6743)
NS	40X6011	Transfer belt
NS	40X6755	MFP cave light assembly
NS	40X6293	Upper paper exit cover (used on 40X6743)
