Каталог запчастей для Lexmark X925 - Electrical 2

№	Номер партии	Описание

1	40X6746	Engine board
10	40X6416	MPF-Engine board cable
11	40X6190	Registration sensor cable
12	40X6748	RIP Harness cable
13	40X6261	Photo interrupter cable (Belt up/down)
14	40X6194	Paperfeed clutch cable
15	40X6165	Exit solenoid cable (w/solenoid)
16	40X6209	Tray lift motor cable
17	40X6171	Fuser fan cable (fan included)
18	40X6367	Engine paperfeed cable
19	40X6161	Drive unit motor (w/motor)
2	40X6747	Engine power supply cable
20	40X6158	Duplex clutch harness
21	40X6749	Main power cable
3	40X6210	Power supply fan cable
4	40X6262	Belt motor cable
5	40X6206	Main fan cable (fan included)
6	40X6203	Humidity sensor cable
7	40X6120	Paper size sensor cable
8	40X6427	Engine board fan cable (fan included)
9	40X6419	MPF clutch
NS	40X7456	Paper tray size switch cable
NS	40X7454	Remote off switch cable
NS	40X7448	Electrical screw parts pack
NS	40X7455	Cover closed actuator cable
