Lexmark X925
12. Paper feed
Каталог запчастей для Lexmark X925 - Paper feed
№
Номер партии
Описание
Примечание
1
40X6176
Paperfeed unit
10
40X6183
Lower registration spring
11
40X6184
Upper registration spring
12
40X6179
Feed roll
13
40X6177
Feed roll gear
14
40X6178
Pickup gear
15
40X6180
Pick roll
16
40X6186
Separator roll
17
40X6187
Torque limiter
18
40X6181
Pickup lever A
19
40X6190
Registration sensor cable
2
40X6193
Registration sensor cable
20
40X6422
Upper registration spring
21
40X6423
Lower registration spring
22
40X6191
Paperfeed clutch
23
40X6194
Paperfeed clutch cable
24
40X6192
Paperfeed unit motor
25
40X6367
Engine paperfeed cable
3
40X1104
Photo sensor
4
40X6189
Registration sensor actuator spring
5
40X6188
Registration sensor actuator
6
40X6195
Static discharge brush
7
40X6581
Standard registration roller
8
40X6580
MPF registration roller
9
40X6185
Registration gear
NS
40X7447
Paper feed screw parts pack
NS
40X6372
Paperfeed maintenance kit
