Каталог запчастей для Ricoh Aficio MP201SPF - Operation Panel


Каталог запчастей для Ricoh Aficio MP201SPF - Operation Panel
Номер партии Описание Примечание
* D067 1436 Operation Panel:NA:D068 (D116)
* D067 1431 Operation Panel:NA:D069 (D115)
* D067 1437 Operation Panel:EU:D068 (D116)
* D067 1435 Operation Panel:EU:D069 (D115)
* D067 1438 Operation Panel:AA:D068 (D116)
* D067 1434 Operation Panel:AA:D069 (D115)
1 B262 1481 Cover:On-line:CPS:EU (D115)
1 B262 1479 Cover:On-line:CPS:NA (D115)
1 B262 1474 Cover:On-line:C (D116)
10 B129 1474 Spring Plate - Stl
101 0452 3010N Binding Self-Tapping Screw:3x10
102 0452 3012N Binding Self-Tapping Screw:M3x12
11 B262 1452 Cover:Lower:Basic
12 B243 1477 Keytop:Copy:NA (D068)
13 B262 1451 Cover:Upper:Basic
14 D067 1495 LCD:168x64DOTS
15 B262 1455 Sheet:Base:Right
16 D067 1450 Sheet:Display:Operation Panel:NA:C4
16 D067 1451 Sheet:Display:Operation Panel:EU:C4
2 B243 1459 Keytop - Cursor
3 B229 1475 Keytop - 10key
3 B229 1526 Keytop - 10key NA
3 B229 1557 Keytop - 10key AA
4 B229 1525 Keytop-Initial
5 B229 1537 Keytop - Clear Modes
6 B243 1458 Keytop - Power Source
7 B229 1454 Keytop - Clear/Stop
8 B229 1453 Keytop - Start
9 D067 1551 PCB:OPU
