Ricoh Aficio MP2352SP
23. Duplex Section 3
Каталог запчастей для Ricoh Aficio MP2352SP - Duplex Section 3
№
Номер партии
Описание
Примечание
1
D120 2956
Guide Plate: Vertical Transport: Lower
10
B223 2676
Spring - 11N
101
0451 3006N
Tapping Screw - 3x6
11
D120 2957
Guide Plate: Vertical Transport: Driven: Upper
12
D120 4699
Hook: Stopper: Rear
13
AA06 1105
Tension Spring: Lever: Duplex
14
D039 2998
Shaft: Grip
15
D120 2996
Grip: Cover: Right
16
D039 2996
Hook: Stopper: Duplex Unit: Front
17
AA04 3584
Timing Belt: S2M288
18
D120 4618
Cover: Right
2
D120 2958
Sheet: Guide: Vertical Transport: Lower
3
D029 2677
Transport Belt: Driven: Vertical Transport
4
D009 2574
Pulley - Idler
5
D009 2573
Pulley - Vertical Transport
6
D009 2571
Holder - Vertical Transport
7
D009 2575
Shaft - Idler
8
D009 2576
Shaft - Vertical Transport
9
G060 2652
Bushing - M4
