Каталог запчастей для Ricoh Aficio MP4000B - ARDF Drive Section 1

№	Номер партии	Описание	Примечание
1	B802 1812	Stepper Motor:DC4.08V 2.4W
10	B802 1925	Bracket:Pickup:Drive
101	0451 3006N	Tapping Screw - 3x6
102	0353 0060N	Bind Screw - M3x6
103	1105 0511	Harness Clamp - LWS-0306ZC
104	1105 0516	Clamp
11	B700 5805	Stepper Motor:PM:S2M:T15:Assy
12	AA08 2101	Bushing - 6x10x6
13	5447 2681	Snap Ring
14	B802 1951	Cam:Stopper Pawl
15	B802 1956	Gear:Stopper:Original Insert:Z25
16	B351 1781	Gear - 18Z
17	B802 1931	Timing Pulley:T33-Z17
18	B802 1942	Stopper:Cam:Pickup
19	5206 2686	Snap Ring
2	AA10 1021	Rubber Bushing - 6 45HS
20	B802 1943	Feeler:Cam:Pickup
21	B802 1946	Gear:Drive:Arm:Pickup
22	B802 1941	Cam:Pickup
3	B802 1815	Bracket:Reverse:Drive
4	B044 1825	Collar
5	J503 3116	Timing Belt:40S2M128
6	G570 1225	Sensor Shielding Plate
7	B802 1985	Bracket:Sensor:Pickup
8	GW02 0020	Photointerruptor:LG248NL1
9	AA04 3323	Timing Belt:40S2M120
