D009 1441 |
Operation Sub-unit:AL-C1:NA:Assy |
|
|
| * |
D092 1412 |
Operation Panel:EU (D091/D092) |
|
|
| * |
D009 1448 |
Operation Sub-unit:AL-C1:KOR:Assy |
|
|
| * |
D009 1415 |
X/O (201001 PCIL) |
|
|
| * |
D009 1412 |
Operation Panel - EU |
|
|
| * |
D092 1413 |
X/O (201012 PCIL) |
|
|
| * |
D092 1411 |
Operation Panel:NA (D091/D092) |
|
|
| * |
D009 1416 |
X/O (201001 PCIL) |
|
|
| * |
D009 1445 |
Operation Sub-unit:AL-C1:TWN:Assy |
|
|
| * |
D009 1411 |
X/O (201001 PCIL) |
|
|
| * |
D092 1443 |
Operation Sub-unit:AL-C1.5:AA:Assy (D091/D092) |
|
|
| * |
D009 1418 |
X/O (200912 PCIL) |
|
|
| * |
D009 1446 |
Operation Sub-unit:AL-C1:CHN:Assy |
|
|
| * |
D009 1413 |
Operation Panel - AA |
|
|
| * |
D092 1415 |
Operation Panel:TWN (D091/D092) |
|
|
| 1 |
B238 1547 |
Spacer - Keytop |
|
|
| 10 |
D009 1486 |
Invertor:TFT |
|
|
| 11 |
D009 1484 |
Harness:Invertor |
|
|
| 12 |
B238 1548 |
Operation Panel Bracket - Right |
|
|
| 13 |
B238 1519 |
Lens - Front |
|
|
| 14 |
D009 1504 |
Shadeing Plate:Touch Panel |
|
|
| 15 |
D009 1488 |
Touch Panel:W-VGA:MA |
|
|
| 16 |
B238 1534 |
LCD Spacer A |
|
|
| 17 |
B238 1535 |
LCD Spacer B |
|
|
| 18 |
D009 1498 |
LCD:TFT:W-VGA:MV |
|
|
| 19 |
D009 1487 |
Cable:FFC:TFT:LCD |
|
|
| 2 |
B238 1511 |
Keytop - Counter |
|
|
| 20 |
B223 1520 |
Keytop - Clear/Stop |
|
|
| 21 |
B223 1540 |
Keytop:10Key:NA |
|
|
| 21 |
B223 1541 |
Keytop - 10Key AA |
|
|
| 21 |
B223 1521 |
Keytop:10Key |
|
|
| 22 |
B238 1583 |
Keytop - Clear Modes |
|
|
| 23 |
B238 1504 |
Keytop - Start |
|
|
| 24 |
B238 1506 |
Keytop - Try Print |
|
|
| 25 |
B238 1509 |
Keytop - Interrupt |
|
|
| 26 |
B238 1552 |
Keytop - Kantan |
|
|
| 27 |
B238 1550 |
Keytop - Login |
|
|
| 28 |
B238 1549 |
Keytop - Power Source |
|
|
| 29 |
D009 1483 |
Harness:OP-L:13 |
|
|
| 3 |
B223 1518 |
Keytop - Blank FB |
|
|
| 30 |
D009 1482 |
Harness:OP-L:12 |
|
|
| 31 |
D009 1466 |
O/O (201010 PCIL) |
|
|
| 31 |
D009 1470 |
PCB:OP-R |
|
|
| 32 |
B223 1532 |
Keytop:Scanner:NA |
|
|
| 32 |
B223 1538 |
Keytop:Scanner:EU |
|
|
| 33 |
B223 1529 |
Keytop - DOC NA |
|
|
| 33 |
B223 1535 |
Keytop:DOC:EU |
|
|
| 34 |
B223 1528 |
Keytop - Copy NA |
|
|
| 34 |
B223 1534 |
Keytop:Copy:EU |
|
|
| 35 |
B222 1595 |
Cover:Scanner:Front:EU |
|
|
| 35 |
B223 1595 |
Cover:Scanner:Front |
|
|
| 36 |
B223 1537 |
Keytop:Printer:EU |
|
|
| 36 |
B223 1531 |
Keytop:Printer:NA |
|
|
| 37 |
B223 1596 |
Cover:Front Right:Upper |
|
|
| 38 |
D009 1502 |
Cover:Lower ADD (200907 PCIL) |
|
|
| 4 |
B223 1497 |
PCB:APC1:OP-L:Sub-assy |
|
|
| 5 |
D009 1480 |
Harness:OP-R:10 |
|
|
| 6 |
D009 1481 |
Harness:OP-R:13 |
|
|
| 7 |
B238 1527 |
Operation Panel Bracket |
|
|
| 8 |
B238 1540 |
Sheet:Data:Display:NA |
|
|
| 9 |
D009 1461 |
PCB - LCDC NA |
|
|
| 9 |
D009 1463 |
X/O (200912 PCIL) |
|
|
| 9 |
D092 1482 |
PCB:ALC1:LCDC:EU:Assy |
|
|
| 9 |
D092 1488 |
PCB:ALC1:LCDC:KOR:Assy |
|
|
| 9 |
D009 1462 |
X/O (201001 PCIL) |
|
|
| 9 |
D092 1483 |
PCB:ALC1:LCDC:TWN/AA:Assy |
|
|
| 9 |
D009 1458 |
X/O (200912 PCIL) |
|
|
