Каталог запчастей для Ricoh Aficio MPC7500SP - Electrical Section 8

№	Номер партии	Описание	Примечание
1	B132 5933	Hinge:C/T Box:Upper
10	D014 5951	Base - C/T Box
11	B070 6877	Large Drum Stay Ground Plate
12	D014 5931	Left Frame - C/T Box
13	B132 1528	Guard:Gap:C/T Box
14	D014 5818	Decal:Caption:Interface
15	D014 5911	Upper Frame - C/T Box
16	B132 5813	Seal:C/T Box:Upper:Side
17	B712 5605	Grip:Application
18	B132 5989	Stopper:C/T Box:Upper
19	AA14 3718	Stepped Screw - M4
2	B132 5930	Hinge:C/T Box:Lower
20	B132 5940	Bracket:C/T Box:Upper
3	B132 5947	Arm:Hinge:C/T Box
4	D014 5921	Right Frame - C/T Box
5	D014 5955	Bracket - IPU/VBCU
6	B132 5951	Lowr Frame - C/T Box
7	B132 5807	Ground Plate:Base:Control Board
8	D014 5953	Supporter:Lower
9	D014 5952	Supporter:Upper
