| 1 |
G052 3258 |
Left Bushing - Registration |
|
|
| 10 |
G175 3267 |
Cleaner Film - Registration |
|
|
| 11 |
G052 3257 |
Right Bushing - Registration |
|
|
| 12 |
M001 5407 |
Harness: Sensor: Connecting |
|
|
| 13 |
G052 3390 |
Toner End Sensor |
|
|
| 14 |
G052 3396 |
Spring - Toner End Sensor |
|
|
| 15 |
G175 3266 |
Upper Guide Plate - Registration |
|
|
| 16 |
G052 3351 |
Decal - Registration |
|
|
| 17 |
G175 3316 |
Registration Roller - Drive |
|
|
| 2 |
AA06 3539 |
Spring - Registration Roller |
|
|
| 3 |
G175 2585 |
Magnetic Clutch - Registration |
|
|
| 4 |
AA08 2144 |
Bushing - 8x12x7 |
|
|
| 5 |
G096 3336 |
Registration Drive Ground Plate |
|
|
| 6 |
G096 1087 |
Paper Tray Spring Plate Assy |
|
|
| 7 |
G175 2551 |
Photosensor |
|
|
| 8 |
G175 3268 |
Registration Sensor Bracket |
|
|
| 9 |
G096 3315 |
Driven Registration Roller Mm14 |
|
|
