Ricoh Aficio SP4210N
7. Transfer Section
Каталог запчастей для Ricoh Aficio SP4210N - Transfer Section
№
Номер партии
Описание
Примечание
1
G096 1019
Transport Guide Pin
10
G052 3624
Separation Terminal
11
G096 1018
Transport Guide
12
G129 6260
Transfer Roller Assy
13
G129 6252
Gear - Transfer Roller
14
G129 6257
Transfer Roller
15
G129 6251
Positioning Roller - Transfer
16
G096 3640
Transfer Guide Plate Assy
17
G096 3641
Transfer Guide Plate Sheet
18
G096 3628
Transport Guide Ground Plate
19
G096 3629
Transport Terminal Guide
2
G052 3627
Spring - Transfer
20
G052 1255
Charge Terminal - High Voltage
21
G052 1254
Inner Terminal - Charge
22
G052 1256
Development Terminal - High Voltage
23
G052 1253
Development Terminal
24
G052 1251
Charge Terminal
25
G129 6255
Bushing
26
M001 1082
Rivet: DIA3.5
27
M001 1081
Supporter: Harness: Main: 2
3
G052 3626
Left Bushing - Transfer
4
G052 3625
Right Bushing - Transfer
5
G096 3621
Separation Electrode Plate
6
G096 3622
Electrode Plate Cover
7
G096 3345
Registration Guide
8
G096 3346
Registration Guide Long
9
G052 3623
Transfer Terminal
