Каталог запчастей для Ricoh Aficio SP8200DN - Duplex Unit 3

№	Номер партии	Описание

1	AA14 3807	Screw:A
10	D009 4661	Reverse Roller - Feed
11	AB01 4161	Reverse Roller Gear
12	B223 4562	Tightener
13	B044 1847	Shoulder Screw
14	B223 4564	Spring:Tightener
15	B223 4526	Timing Belt:30S2M268
16	B223 4586	Pulley:T30
17	B223 4572	Stepper Motor:DC4.29V 1.7W
18	AA10 1021	Rubber Bushing - 6 45HS
19	B223 4575	Bracket:Stepper Motor
2	D009 4504	Upper Guide Plate - Gate
20	B223 4571	Gear:Pulley:Z24/T40
21	B223 4573	Timing Belt:30S2M128
22	B044 1825	Collar
23	B223 4501	Guide Plate:Right
24	D009 4521	Harness Bracket
25	D009 4497	Decal - Right Guide
26	D009 4652	Motor Harness
3	AA08 2101	Bushing - 6x10x6
4	B223 4566	Bracket:Sensor:Entrance
5	AW01 0107	Paper Feed Sensor
6	D009 4664	Driven Roller
7	B223 4560	Tension Spring:Driven Roller
8	B223 4552	Bushing:DIA4
9	AW02 0145	Photointerruptor:Flat
