Каталог запчастей для Ricoh Aficio SP9100DN - ELECTRICAL SECTION 8

№	Номер партии	Описание	Примечание
1	B132 6726	Bracket:Arm:Assy
10	B065 5700	Rear Paper Bank Harness
11	AA06 3880	Spring
12	AA14 3797	Connector Guide Pin
13	B132 6763	Bracket:Connector:Left
14	B247 6177	Bracket - Paper Size Sensor
15	B247 6800	Harness - Paper Size Sensor
16	AW50 0010	Push Switch
17	AA06 3268	Connector Spring
18	B065 6172	Paper Tray Stopper
19	B065 5878	Upper PSU Stay
2	AA13 2203	Spacer - 6mm
20	B132 6762	DC Solenoid:Coupling:Assy
3	B065 6769	Lock Arm
4	B247 6754	Lock Spring - Small
5	B247 6753	Lock Spring - Large
6	B132 6759	DC Motor:Rise:Tandem LCT:Assy
7	B132 6765	DC Solenoid:Lock:Assy
8	AX04 0144	DC Motor:Rise:Paper Tray
9	B065 6767	Right Connecting Bracket
