Каталог запчастей для Ricoh Aficio SP9100DN - FUSING UNIT 3

№	Номер партии	Описание

1	AE03 2014	Bushing - 30x35x13.5
10	AW11 0026	Thermostat - 180C
11	AW11 0027	Thermostat - 179C
12	B065 4150	Front Harness
13	B065 4121	Thermostat Terminal
14	B065 4151	Rear Harness
15	AW10 0076	Thermistor:Inner Back
16	B065 4131	Rear Thermistor Bracket
17	B065 4170	Rear Heater Holder
18	B065 4159	Harness Holder
19	B065 4157	Connector Bracket
2	AE03 0017	Ball Bearing - 35x50x10
20	B065 4156	Fusing Harness (230V)
20	B065 4155	Fusing Harness (120V)
21	A247 4249	Connector - 3P
22	AB01 2316	Fusing Gear
23	AE01 1087	Hot Roller
24	AX44 0163	Fusing Lamp - 120V 550W
25	AX44 0164	Fusing Lamp - 230V 550W
26	AE03 0018	Ball Bearing - 12x28x8
27	AE02 0112	Pressure Roller
28	AA14 0823	Pressure Roller Shaft
29	B065 4180	Spacer - 16mm
3	B065 4124	Front Heater Holder
4	A413 1670	Antistatic Brush
5	B065 4132	Middle Thermistor Cover
6	AW10 0084	Middle Thermistor
7	B065 4130	Thermostat Housing - Middle
8	G148 4142	Stay:Fusing:Upper:Assy
9	B065 4127	Thermostat Housing
