Каталог запчастей для Samsung CLX6260FD - FRAME-BRACKET MP


Каталог запчастей для Samsung CLX6260FD - FRAME-BRACKET MP
Номер партии Описание Примечание
0 JC93-00750A FRAME-BRACKET MP, CLP-680ND,XAA JC93-00739A
1 JC93-00790A FRAME-REGI, CLP-680ND JC93-00750A
1-1 JC66-03633A ROLLER-REGI,CLP-680ND,EPDM,PI14,L269,GRA JC93-00790A
1-2 JC61-05611A ROLLER-REGI IDLE,CLP-680ND,POM,20,12,ROL JC93-00790A
1-3 JC66-03611A ACTUATOR-REGI SENSOR, CLP-680ND,PC+GF,2T, JC93-00790A
10 JC61-05412A BRACKET-MP,CLP-680DW,EGI-SECC,0.8T,400,1 JC93-00750A
11 JC93-00787A FRAME-ROLLER_MP, CLP-680ND JC93-00750A
2 JC93-00673A FRAME-PICKUP ONEWAY, CLP-470N,XAA JC93-00750A
2-1 JC61-05370A HOLDER-PICKUP,CLP-680ND,ABS+PC,59.8 JC93-00673A
2-2 JC66-02939B ROLLER-MAT_RETARD, ML-2955ND,EPDM,OD 16,2 JC93-00682A
2-3 JC66-03047A CLUTCH-P-ONEWAY, ML-2955ND,POM JC93-00673A
2-4 JC66-01918A GEAR-IDLE PICK UP, CLX-3170FN,POM,0.5,20, JC93-00795A
3 0604-001415 PHOTO-INTERRUPTER, TR,DIP-4,BK JC97-04169A
4 6602-001721 BELT-TIMING GEAR, S2M250,RUB(CR),L250 JC93-00750A
5 JC66-03620A SHAFT-PICK UP,CLP-680ND,PC,147.5,6,NH-10 JC93-00750A
6 JC61-05447A GUIDE-PICKUP,CLP-680ND,HIPS,BLACK,PATH JC93-00750A
7 JC47-00035A CLUTCH-ELECTRIC Z41, ML-2950ND,DC24V 10% JC93-00795A
8 JC93-00791A FRAME-FEED MP, CLP-680ND JC93-00750A
8-1 JC66-03608A ACTUATOR-FEED MP,CLP-680ND,PC,BLACK,ACTU JC93-00791A
8-2 JC61-03973A HOLDER-SHAFT,ML-1660,POM,21.8,BLACK JC93-00791A
9 JC61-05529A HOLDER-SHAFT MP,CLP-680ND,POM,1.5,12.5,3 JC93-00750A
