Каталог запчастей для Samsung SCX4521F - Main Frame Assembly

№	Номер партии	Описание

0	JC96-03392B	ELA HOU-FRAME_LOWER
1	JC61-01152A	FRAME-M-BASE
10	JC61-00836A	FOOT-FRONT
11	JC66-00805A	GEAR-RDCN 113/83
12	JC66-00806A	GEAR-OPC DR 76/38/29
13	JC66-00807A	GEAR-FUSER DR 63/35
14	JC66-00808A	GEAR-FEED DR 41
15	JC66-00822A	LEVER-M-ACTUATOR_EMPTY
16	JB61-00076A	SPRING ETC-TORSION DOC (CC2-F)
17	JC63-00622A	GROUND-P-OPC
19	JC67-00110A	CAP-M-MOTOR
2	JC97-02218A	MEA UNIT-PLATE KNOCK_UP
2-1	JC61-01158A	PLATE-M-KNOCK_UP
2-2	JC66-00720A	SHAFT-P-CORE
2-3	JC72-01004A	PMO-IDLE KNOCK UP MP
2-4	JC74-00011A	MPR-PAD KNOCK UP MP
20	6107-001240	SPRING-CS
21	JC96-03797A	ELA HOU-CRUM
21-1	JC61-01587A	PLATE-M_HINGE
21-2	JC61-00011A	SPRING ETC-FEED
21-3	JC61-01586A	PLATE-M_CRUM
21-4	JC92-01763A	CRUM_P PBA
21-5	6003-000282	SCREW-TAPTITE
3	JC61-01258A	SPRING ETC-TORSION DEVE_L
4	JC61-01259A	SPRING ETC-TORSION DEVE_R
5	JC96-03592A	ELA UNIT-RX DRIVE
5-1	JC61-01465A	BRACKET-P-GEAR_SN
5-2	JC61-01449A	BRACKET-P-MOTOR
5-3	JC66-00804A	GEAR-RDCN 139/83
5-4	JC31-00037D	MOTOR STEP-MAIN
5-5	JC72-00825A	PMO-IMPELLER_DRV
6	JC97-02327B	MEA UNIT-FRAME PATH
7	JC70-00500C	ADJUST-CASSETTE_R
8	JC70-00499C	ADJUST-CASSETTE_L
9	JG66-40003A	GEAR-PINION
