Каталог запчастей для Samsung SCX4521F - Pick up - Assy

Каталог запчастей для Samsung SCX4521F - Pick up - Assy
№ Номер партии Описание Примечание
0 JC96-04232A ELA HOU-ADF
1 JC96-03380B ELA HOU-ADF LOWER
1-1 JC63-00656C COVER-ADF LOWER
1-10 JC72-01011A PMO-ACTUATOR SCAN SENSOR
1-11 6107-001135 SPRING-CS
1-12 JC75-00095A MEC-BRUSH ANTISTATIC
1-13 JB61-00076A SPRING ETC-TORSION DOC (CC2-F)
1-14 JC61-01179A PLATE-M_WHITE BAR
1-15 JC72-01011A PMO-ACTUATOR SCAN SENSOR
1-16 JC66-00460A SHAFT-M-FEED GEAR 38
1-17 JC72-01010A PMO-ACTUATOR REGI SENSOR
1-18 JC66-00560A ROLLER-DRIVE
1-19 JC61-00712A GUIDE-STACKER SUB
1-2 JC96-03379A ELA HOU-ADF MOTOR
1-2-10 JC66-00458A GEAR-IDLE 35 ADF
1-2-11 JC66-00456A GEAR-40/21 ADF
1-2-12 JC66-00455A GEAR-58/25 ADF
1-2-13 JB66-00101A GEAR-CLUTCH 29
1-2-14 JB72-00844A PMO-WHITE CLUTCH SUB 29
1-2-15 JC66-00322A GEAR-CLUTCH 39
1-2-16 6044-000001 RING-CS
1-2-17 6031-001051 WASHER-PLAIN
1-2-2 JC61-01178A BRACKET-M-GEAR
1-2-3 JC61-01180A BRACKET-P-MOTOR
1-2-4 JC31-00036A MOTOR STEP-ADF
1-2-5 JC66-00556A IMPELLER-ADF
1-2-6 6003-000196 SCREW-TAPTITE
1-2-7 JC66-00454A LINK-M-SWING ADF
1-2-8 JB70-00070A IPR-WASHER WAVE
1-2-9 JC66-00457A GEAR-SWING 31/20 ADF
1-20 JC66-00594A SHAFT-STACKER
1-3 JC92-01618A PBA SUB-ADF
1-4 JC63-00667A GROUND-P-ADF
1-5 JC39-00407A CBF HARNESS-ADF
1-6 JC66-00559A ROLLER-EXIT
1-7 JB72-00819A PMO-BUSH
1-8 JC66-00310A GEAR-AGITATOR-2
1-9 6044-000159 RING-C
2 JC97-02804A MEA UNIT-ADF UPPER
2-1 JC63-00657C COVER-M_ADF UPPER
2-2 JC97-01709A MEA UNIT-HOLDER ADF
2-2-1 JC61-00694A HOLDER-M-ADF
2-2-2 JC63-00243A SHEET-ADF HOLDER
2-2-3 JB73-00052A RMO-ADF RUBBER
2-2-4 JC61-00387A SPRING ETC-PAD
3 JC97-02801A MEA UNIT-COVER OPEN
3-1 JC63-00658C COVER-M_ADF OPEN
3-2 JC97-02203A MEA UNIT-PICKUP
3-2-10 6031-000023 WASHER-PLAIN
3-2-11 JB75-00299A MEC-ADF ROLLER ASSY
3-2-11-1 JB72-00822A PMO-SLEEVE ADF
3-2-11-2 JB73-00054A RMO-ADF ROLLER
3-2-12 JB66-00104A GEAR-ADF IDLE 34
3-2-13 JB70-00168A ICT-PIN ADF
3-2-14 JB66-00102A GEAR-PICK UP IDEL 38
3-2-15 JB75-00300A MEC-PICK UP ROLLER ASSY
3-2-15-1 JB72-00823A PMO-SLEEVE PICK UP
3-2-15-2 JB73-00055A RMO-PICKUP ROLLER
3-2-16 JC72-00744A PMO-SHAFT PICK UP
3-2-17 JB72-00845A PMO-PICK UP CLUTCH SUB
3-2-18 JB66-00105A GEAR-PICK UP 26
3-2-2 6044-000159 RING-C
3-2-3 JB66-00103A GEAR-ADF 38
3-2-4 JC72-41191A PMO-BEARING SHAFT
3-2-5 JB72-00817A PMO-ADF CLUTCH
3-2-6 JB72-00821A PMO-ADF COLAR
3-2-7 JB61-70904A SPRING ETC-CLUTCH
3-2-8 JC66-00839A SHAFT-M-ADF
3-2-9 JC72-00734A PMO-COVER ADF
3-3 JB72-00819A PMO-BUSH
3-4 JB72-00843A PMO-GUIDE PAPER
4 JC97-02802A MEA UNIT-COVER PLATEN
