Каталог запчастей для Samsung SCX4729FW - Frame Main

Каталог запчастей для Samsung SCX4729FW - Frame Main
№ Номер партии Описание Примечание
1 JC97-03958A LSU ML-2950,SEC,Single,A4(Ltr),600,S1,78 JC93-00424A
10 JC93-00411A FRAME-CRUM ML-2950ND,SEC JC93-00430A
11 JC93-00414A FRAME-PAPER_PATH ML-2950ND,SEC JC93-00424A
12 JC66-03028A GEAR-RDCN ML-2950ND,POM,0.6/0.8,z23,WHT, JC93-00424A
13 JC66-03012A GEAR-DUPLEX DR ML-2950ND,POM,0.6,z28,WHT JC93-00424A
14 JC93-00418A DRIVE-DUPLEX SWING ML-2950ND,SEC JC93-00424A
15 JC90-01109A DUPLEX ML-2955ND,SEE JC93-00424A
16 JC61-04358A PLATE-FRAME_BOTTOM ML-2950ND,SECC,0.8T JC93-00424A
17 JC93-00426A FRAME MAIN-RIGHT SCX-4729FD,SEE JC93-00424A
18 JC93-00402A FRAME-TERMINAL ML-2950ND,SEE JC93-00424A
19 JC44-00205A HVPS 24V,21.6V27.6V,MAX 5KV,MAX-2KV,600 JC93-00424A
2 JC39-01530A FLAT CABLE ML-2950ND,12P, 14P,0.05,370mm JC93-00424A
20 JC63-03162A SHEET-INSULATOR ML-2950ND,PC,0.254,181,7 JC93-00424A
21 JC44-00206A SMPS-V2 ML-2950ND,P4M-SMP-2130_HYB-00-V2 JC93-00424A
22 JC66-03014A GEAR-FEED ML-2950ND,POM,0.8,z16,WHT,SPUR JC93-00424A
23 JC93-00425A FRAME MAIN-LEFT SCX-4729FD,SEE JC93-00424A
24 JC47-00036A CLUTCH-ELECTRIC Z45 ML-2950ND,DC24V 10% JC93-00424A
25 JC47-00035A CLUTCH-ELECTRIC Z41 ML-2950ND,DC24V 10% JC93-00424A
26 JC31-00146A FAN 50*50*20,24V JC93-00424A
27 JC61-04373A HOLDER-FAN ML-2950ND,PP,BLACK,HJ500R165 JC93-00424A
28 JC92-02406A PBA-JOINT ML-2950ND,JOINT,45mmX20mm,FR1, JC93-00424A
29 JC66-03023A GEAR-RDCN EXIT ML-2950ND,POM,0.5/0.8,z74 JC93-00424A
3 JC61-04357A BRACKET-LSU ML-2950ND,SECC,0.8T JC93-00430A
30 JC66-03017A GEAR-IDLE EXIT ML-2950ND,POM,0.8,z29,WHT JC93-00424A
31 JC66-03013A GEAR-EXIT ML-2950ND,POM,0.8,z18,WHT,SPUR JC93-00424A
4 JC93-00410A FRAME MAIN-EXIT ML-2955ND,Cream white JC93-00424A
5 0604-001393 PHOTO-INTERRUPTER TR,75mW,BGA,TR JC93-00429A
6 JC61-04388A HOLDER-EXIT_SENSOR ML-2950ND,PC,BLACK,23 JC93-00429A
7 JC61-04383A PLATE-FUSER ML-2950ND,SECC,1.0T,275.5,37 JC93-00429A
8 JC66-01218A ROLLER-TRANSFER SCX-4200,NBR+ECO,15,218m JC93-00424A
9 JC61-04068A HOLDER-TR ML-3700,ABS,2,24.4,9,ICE GREEN JC93-00424A
