Каталог запчастей для Samsung SCX6545NX Finisher - Ejector Unit

№	Номер партии	Описание	Примечание
0	JC81-03773A	AS-EJECTOR UNIT ASSY
1	-	FRMAE:FRONT:EJECT
1	-	FRMAE:FRONT:EJECT
10	JC81-03502A	AS-GEAR M08Z19M05Z50
11	JC81-03501A	AS-PULLEY S2MT40M05T24
12	-	BKT:DC MOTOR:EJECT
12	-	BKT:DC MOTOR:EJECT
13	0604-001095	PI SENSOR:GP1S73P2
14	JC81-03474A	AS-MOTOR EJECT
15	C81-03500A	AS-BELT B35S2M118J
16	-	MICRO WIRE SADDLE
16	-	MICRO WIRE SADDLE
17	-	FRAME:BELT:EJECT:FRONT
17	-	FRAME:BELT:EJECT:FRONT
18	JC61-00424A	BUSH-4_D
19	C81-03499A	AS-PULLEY S2M34TJ
2	-	T-SPRING:LATCH:SCU
2	-	T-SPRING:LATCH:SCU
20	-	PLATE SPRING:TIGHTNER:EJECT
20	-	PLATE SPRING:TIGHTNER:EJECT
21	-	PARALLEL PIN:2x10
21	-	PARALLEL PIN:2x10
22	JC81-03498A	AS-PULLEY S2M20T
23	JC81-03497A	AS-PULLEY DRVS2M34T
24	JC81-03496A	AS-PULLEY S2M25T
25	JC81-03513A	AS-BELT B35S2M144
26	-	FRAME:BERO
26	-	FRAME:BERO
27	JC81-03512A	AS-BELT ASSY EJECT
27-1	-	BELT-EJECT B130S2M370
27-1	-	BELT-EJECT B130S2M370
27-2	-	HOLER-BELT EJECT
27-2	-	HOLER-BELT EJECT
28	-	SHAFT:BELT TRANS:EJECT
28	-	SHAFT:BELT TRANS:EJECT
29	-	SHAFT:SCU
29	-	SHAFT:SCU
3	-	HOOK:CAM:EJECT
3	-	HOOK:CAM:EJECT
30	-	HOLDER:SCU
30	-	HOLDER:SCU
31	-	PADDLE:SCU
31	-	PADDLE:SCU
32	-	ASSY:M/H:EXT TRAY HOME SNR
32	-	ASSY:M/H:EXT TRAY HOME SNR
33	-	SHAFT D-CUT:GRIP HINGE:EJECT
33	-	SHAFT D-CUT:GRIP HINGE:EJECT
34	-	GRIP BASE:FRONT:EJECT
34	-	GRIP BASE:FRONT:EJECT
35	-	GRIP LINK:EJECT
35	-	GRIP LINK:EJECT
36	-	E-SPRING:GRIP
36	-	E-SPRING:GRIP
37	-	SHAFT:GRIP HINGE:EJECT
37	-	SHAFT:GRIP HINGE:EJECT
38	-	GRIP BASE:REAR:EJECT
38	-	GRIP BASE:REAR:EJECT
39	-	ROLLER:GRIP:EJECT
39	-	ROLLER:GRIP:EJECT
4	JC81-03526A	AS-GEAR CAM SCU
40	-	PIN:ROLLER:EJECT
40	-	PIN:ROLLER:EJECT
41	-	FRAME:BELT:EJECT:REAR
41	-	FRAME:BELT:EJECT:REAR
42	-	FRAME:RETURN:EJECT
42	-	FRAME:RETURN:EJECT
43	-	FRAME:REAR:EJECT
43	-	FRAME:REAR:EJECT
44	-	ROTATOR:CAM:SCU
44	-	ROTATOR:CAM:SCU
45	-	HOOK:SPRING:SCU
45	-	HOOK:SPRING:SCU
46	-	E-SPRING:CLUTCH:SCU
46	-	E-SPRING:CLUTCH:SCU
47	JC81-03772A	AS-EJT BELT SUBASSY
48	-	SHAFT:BELT PULLEY:EJECT
48	-	SHAFT:BELT PULLEY:EJECT
49	JC61-00423A	BUSH-6_D
5	-	E-RING:4
5	-	E-RING:4
6	JC81-03495A	AS-SPUR GEAR Z19
7	-	ASSY:BKT:DRIVING:EJECT
7	-	ASSY:BKT:DRIVING:EJECT
8	JC81-03504A	AS-SPUR GEAR Z30
9	JC81-03503A	AS-SPUR GEAR Z19 SCU
