Каталог запчастей для Xerox Phaser 3040 - Feeder 2


Каталог запчастей для Xerox Phaser 3040 - Feeder 2
Номер партии Описание Примечание
1 059K71563 Roll Assy MSI (with 1-7) (Feed Roll Assembly)
10 Plate BTM
11 Holder BTM L
12 Holder BTM R
13 Follower L
14 Follower R
15 848K49666 Housing Assy Pad (Separator Pad Assembly)
16 Arm MSI R
17 Spring NF
18 Arm MSI L
19 807E36162 Feed Gear
2 Cam MSI L
20 Spring Feed
3 Roll Core
4 Roll Assy Feed
5 Holder Feed
6 Shaft Feed
7 Cam MSI R
8 815K07610 Plate Assy Bottom (with 9,10) (Bottom Plate)
9 Pad MSI
